VP & UD Bushes

VP & UD Bushes

Designed to accommodate torsional movement and axial and radial loads. The rubber is pre-stressed to give maximum dynamic strength and durability. Excellent sound and vibration isolation characteristics.

Typical uses:

  • Vehicle Suspension
  • Pivot Arms
  • Conveyor Tracks
  • Vibratory Feeders
  • Mechanical Linkages

VP Bush





Contact us for more information.

See table below for standard sizes. More sizes available.

UD Bush
Part Number ID OD IL OL Shore
13-1459-01 7.92 25.4 33.32 25.4 50
17-1459-05 7.92 25.4 33.32 25.4 70
13-1232-60 8 20 17 15 60
13-1027-01 9.53 20.63 11.69 8.64 70
13-2370-00 9.58 21.9 21.02 17.85 60
13-2309-01 10 22 33 30 70
13-1230-00 10 24 18 15 55
13-1353-01 12.7 25.4 16.51 13.84 60
13-1460-00 12.7 28.8 28.58 25.4 60
13-1657-00 12.7 38.1 50.8 44.45 60
13-2291-00 12.8 38.1 77.77 73.02 35
13-2291-01 12.8 38.1 77.77 73.02 45
13-2201-02 12.8 38.1 77.77 73.02 55
13-2201-03 12.8 38.1 77.77 73.02 60
13-0797-04 15.88 33.32 65.07 60.32 60
13-0797-00 15.88 33.32 65.07 60.32 70
13-1004-01 15.88 47.63 50.8 44.45 60
13-0917-00 16 30.15 31.8 28.66 60
13-0754-13 17.54 35 39.8 35.05 75
13-0927-01 19.05 38.1 61.85 57.15 60
13-0922-02 28.57 54.61 57.15 50.8 45
13-0989-00 28.57 57.15 89 85.73 60
13-2017-00 31.75 50.8 27.17 24.13 60
13-1698-03 34.93 71.12 44.95 41.15 60
13-0728-01 34.93 71.12 120.65 111.1 60
13-0803-00 44.45 88.9 101.6 79.38 60
13-1317-01 50.8 100.78 158.75 146 75
13-0900-01 55.39 81.5 81.28 76.2 60
13-0997-00 55.39 81.5 90.42 77.47 60
13-1414-01 76.25 142.85 193.69 190.5 70
VP Bush
Part Number ID OD IL OL Shore
VP 10/2525 10 25 25 20 60
VP 10/2540 10 25 40 35 60
VP 15/3530 15 35 30 25 60
VP 15/3550 15 35 50 45 60
VP 20/4540 20 45 40 35 60
VP 20/4575 20 45 75 70 60
VP 25/5045 25 50 45 40 60
VP 25/5085 25 50 85 80 60
VP 30/6055 30 60 55 45 60
VP 30/60100 30 60 100 90 60
VP 40/7065 40 70 65 55 60
VP 50/8075 50 80 75 65 60
