UH Mount

UH Mounting

UH is an anti-vibration mounting designed to accommodate axial static and shock loads in both directions. The dynamic natural frequency is constant irrespective of the static load.
Mounting UH is particularly suitable for the suspension of both mobile and static cabs as well as platforms on agricultural vehicles. Effectively isolating vibration and noise, the UH-mounting also protects tanks and ancillary equipment against metal fatigue caused by chassis distortion.

Typical uses:

  • Tractors
  • Combine Harvesters
  • Wheel-Mounted Loaders
  • Street Sweepers
  • Compactors
  • Lifting Cranes
  • Construction Vehicles
  • Off-Road Equipment
  • Fork-Lift Trucks
  • Excavators





Contact us for more information.

See table below for standard sizes. More sizes available.

Part Number K A H C d D1 Weight (kg) M-Max (kg)
UH 50 100.5 80.4 37 91 10.5 15 0.41 250
UH 70 100.5 80.4 37 91 10.5 17 0.41 400
