Metacone & HK Washers

Metacone & HK Washers

Overload and rebound washers (top and bottom) are necessary to limit maximum in the event of shock loading.





Contact us for more information.

See table below for standard sizes.

Recommended tightening torque for centre fixing bolts
Thread Size Torque (Nm)
M10 25
M12 40
M16 60
M20 120
M24 200
Washer
Designation Type A B C D E
Washer 50x12C C 50 12 3 3 28.5
Washer 95x24C C 95 24 8 6 38
Washer 67.5x20C C 67.5 20 5 5 30
Washer 116x24B B 116 24 8 4 47
Washer 80x20B B 80 20 6 3 34.5
Washer 55x12B B 55 12 5 2.5 25
Washer 80x16B B 80 16 6.5 3 31.5
Washer 50x10A A 50 10 4
Washer 80x16A A 80 16 5
Washer 100x20A A 100 20 6
Washer 139x24A A 139 24 10
Washer 55x12A A 55 12 5
Washer 51x16A A 51 16 4
Washer 57x16B B 57 16 3 1.5 22
Washer 52x16A A 52 16 3
Washer 110x20B B 110 20 5 3 52.5
Washer 55x20A A 55 20 5
Metacone & HK on page 40
Type Cone Mount Top Washer Bottom Washer
Metacone 17-0189 Washer 55x12B Washer 50x12C
17-0241 Washer 55x12B Washer 50x12C
17-0248 Washer 55x12B Washer 50x12C
17-0277 Washer 80x16B Washer 80x16A
17-0379 Washer 50x10A Washer 50x10A
17-0341 Washer 80x16B Washer 80x16A
17-0311 Washer 80x16B Washer 80x16A
17-1691 Washer 55x12A Washer 51x16A
HK HK 60 Washer 57x16B Washer 52x16A
Metacone & HK on page 42
Type Cone Mount Top Washer Bottom Washer
Metacone 11-1009 Washer 80x16A Washer 80x16A
17-0391 Washer 80x16A Washer 80x16A
17-0566 Washer 80x16A Washer 80x16A
17-1227 Washer 80x20B Washer 67.5x20C
17-1550 Washer 139x24A Washer 139x24A
17-1843 Washer 100x20A Washer 100x20A
17-1865 Washer 80x16A Washer 80x16A
17-0146 Washer 116x24B Washer 95x24C
HK HK 600 Washer 110x20B Washer 55x20A
